1. Incredible Immersion with Ultra-Narrow Bezel
The LC-MU5505H series video wall provides an immersive experience thanks to its ultra-narrow 3.5 mm bezel-to-bezel, while its outstanding IPS panel delivers a clear image from virtually any angle. The design of this video wall display is attractive and highly functional and can be used to deliver advertising and information in a variety of business environments.
2. 3.5mm Ultra-narrow Bezel
The 3.5mm ultra-narrow bezel of the LC-MU5505H video wall creates a visually stunning digital wall that delivers dynamic content and immerses the viewer. The 55” screens can be combined to create a virtually seamless large screen.
3. Image Gap Reduction
The LC-MU5505H series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a virtually seamless viewing experience.
4. Higher Viewing Angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the LC-MU5505H series is high enough to display vivid colors throughout the screen with virtually no distortion.
SPECIFICATIONs
| Model Name | LC-MU5505H | |||||
| Screen Size | 55" | |||||
| Active Display Area | 1213.4mm(W) x 684.2mm(H) | |||||
| Display Model | 16:09 | |||||
| Resolution | 1920x1080 | |||||
| Display Color | 1.06B (8bit) | |||||
| Pixel Pitch(mm) | 0.630(H) x 0.630(V) | |||||
| Brightness (nits) | 500cd/㎡ | |||||
| Contrast | 1400:1 | |||||
| View Angle (H/V) | 178°/178° | |||||
| Response Time | 15ms | |||||
| Bezel Gap | 3.5mm | |||||
| Backlight | LED | |||||
| Input and Output / Video Wall Controller (Built-in each Screen) | ||||||
| Input | VIDEO (BNC x 1)、Y,Pb,Pr/Y,Cb,Cr (BNC x 3)、S-video （optional） | |||||
| HDMI x 1、 DVI x 1、 SDI (optional) | ||||||
| VGA x 1 | ||||||
| Output | VIDEO (BNC x 1) | |||||
| Control signal input and loop out | RJ45 x 1 | |||||
| RJ45 x 2 | ||||||
| ISP Upgrade Input | RJ45 x 1 / USB | |||||
| Video System | ||||||
| Color System | PAL/NTSC/SECAM | |||||
| compatible HDTV Mode | 480P,576P,720P,1080I, 1080P | |||||
| 3D Combfilter | YES | |||||
| OSD Display | Chinese/English | |||||
| Power | ||||||
| Power Supply | AC100V～240V 50/60Hz | |||||
| Maximum Power Consumption | ≤165W | |||||
| Control Mode | RS232 control, Remote Control, External Matrix Control | |||||
| Temperature | ||||||
| Working Temperature | 0℃～50℃ | |||||
| Working Humidity | 20%-80% | |||||
LCD Video Wall vs. LED Video Wall:
Video walls are a great way to attract attention and promote your brand. However, with several video wall options available in the market, choosing the right one can be a daunting task. Two popular choices for video walls are LCD and LED.
LCD Video Wall
Pros:
1. High-resolution display: LCD video walls provide ultra-high definition resolution, making them ideal for displaying detailed images and videos.
2. Wide viewing angles: With an overall narrow bezel, an LCD video wall provides an immersive viewing experience from almost any angle.
3. Durability: LCD video walls are designed to last longer and offer reliability and durability.
Cons:
1. Limited brightness: Compared to LED, LCD video walls have lower brightness levels, which can limit their visibility in bright environments.
2. Power consumption: LCD video walls require more energy to run, making them less energy efficient than LED video walls.
3. Higher cost: LCD video walls are more expensive compared to LED video walls because of their high-tech features.
LED Video Wall
Pros:
1. Brightness and contrast: LED video walls have high brightness and contrast levels, making them ideal for outdoor and indoor spaces with varying light conditions.
2. Energy efficiency: LED video walls consume less energy than LCD video walls, leading to lower operating costs.
3. Wide availability: LED technology is readily available, which makes the cost of LED video walls more affordable.
Cons:
1. Pixel pitch: LED video walls can have noticeable pixelation at a closer viewing distance due to their pixel pitch.
2. Viewing angles: viewing angle can be an issue with LED video walls, as they display differently from different angles.
3. Longevity: LED pixels are more prone to failure than LCD pixels, leading to pixel burnouts
